OUCO (Wuxi) Injection Molding Machinery Equipment Co., Ltd.

Contact Now

CE Plastic Product Injection Molding Machine PC 160t Injection Molding Machine

Name: CE Plastic Product Injection Molding Machine PC 160t Injection Molding Machine
Brand: OUCO
Price: 1 USD

Wholesale CE Plastic Product Injection Molding Machine PC 160t Injection Molding Machine from china suppliers

Brand Name : OUCO

Model Number : OUCO-160T

Certification : CE

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 500 sets per year

Delivery Time : 1 months

Packaging Details : shipping container

Product Name : Various Types of Plastic Product Injection Molding Machine For Sale

Plastic Processed : PP, PC

Distance between Tie Bars(Width) : 505mm

Weight : 5500 kg

Plasticizing Capacity(g/s) : 18-33

Ejector Number : 13

Mold Height : 180 - 510 mm

Ejector Force : 49 kN

Clamping Force : 1600KN

Application : Plastic Produc

Contact Now

Various Types of Plastic Product Injection Molding Machine For Sale

Efficient plasticizing screws with large length to diameter ratio (designed by Germany).

The central clamping structure honor invention patent of China.

Enlarge plasticizing motor. Enlarge ejector force, Multiple options of core- pulling modes. Independent R& D for super- energy servo system with high efficiency.

CE Plastic Product Injection Molding Machine PC 160t Injection Molding Machine

Essential Details

Plastic Processed:	PP, PC	Injection Weight (g):	329 g
Distance between Tie Bars(Width)(mm):	505mm	Screw diameter (mm):	45 mm
Distance between Tie Bars(Height)(mm):	405mm	Screw L/D Ratio:	20.4
Plasticizing Capacity(g/s):	18-33	Weight (KG):	5500 kg
Mold Height(mm):	180 - 510 mm	Open Stroke(mm):	480 mm
Ejector Number:	5	Power (kW):	22 kW
Ejector Stroke(mm):	140 mm	Warranty:	1 Year
Ejector Force(kN):	49 kN	Key Selling Points:	High-accuracy
Theoretical Shot Volume:	358 cm	Applicable Industries:	Hotels, Manufacturing Plant, Retail
Injection Rate (g/s):	166-204cm3	Showroom Location:	United States, India, South Africa
Machine Type:	Hydraulic	Certification:	ISO9001:2008,CE,TUV

Main Features

Enlarged hydraulic system and pump servo motor.

Enlarged the torque of the plasticization motor.

Enlarged ejector force.

Advance injection screw design for PET.

Chrome plated injection screw and barrel flange.

Leading technology and performance.
China unique producer, central locking toggle.
Injection molding compounders (CIML) fill the blank in Asia.
Electro-hydraulic hybrid 2 platen machines are special for automotive industry with the leading level.

CE Plastic Product Injection Molding Machine PC 160t Injection Molding Machine

Ensure the stability of power output for a long time

Oil electric hybrid precision injection molding machine combines the advantages of high-speed and precision of all electric injection molding machine and large continuous output torque of hydraulic motor. It is more effective for specific molding products and longer service life. OUCO's oil electric hybrid, mold opening and closing, glue injection and pressure maintaining adopts the servo motor to directly drive the rolling lead screw to ensure the position accuracy of 0.02mm. The hydraulic driving mode is adopted for the movement of the shooting table, ejection, mold adjustment and glue melting. It ensures the stability of power output for a long time.

CE Plastic Product Injection Molding Machine PC 160t Injection Molding Machine

OUCO oil electric hybrid injection molding machine has the advantages of full motor and oil press

The response speed of the whole motor, fast injection response, high speed, full closed-loop control, high precision and short operation cycle

It is suitable for high-speed positioning and high-precision mold opening and closing products

It can realize the synchronous action of glue melting, mold opening and closing and ejection (core pulling and inserting), and improve the production efficiency

Power saving than oil compressor

It is easier to add core pulling device than full motor

Higher cost performance than full motor

CE Plastic Product Injection Molding Machine PC 160t Injection Molding Machine
